North American Clutch Driveline AIR BURNERS INC. S-300 Series w/Kubota V3300 uses NACD Clutch Model 434510AM NACD Power Take-Off Service Manual 6. NOTE NACD does not supply outboard bearings. 4. 7. a The power take off must be bolted to the engine. The part number format for an NACD Power Take-Off is 4XXXXXAM where XXXXX is a 5 digit alpha number unique to that particular assembly. Pilot bearing size and type are integral to allowable side load p...
