This document serves as a subdivision plat for Green Bench Gardens Avenue, outlining a two-lot minor subdivision of Lot 2 of Orchard Home Company's Addition No. 6, located in Misoula County, Montana.

How to fill out subdivision plat - co

How to fill out Subdivision Plat

1. Gather necessary documents and information about the property.
2. Determine the required scale and size for the plat based on local regulations.
3. Clearly outline the boundaries of the property.
4. Identify and label all existing and proposed features such as roads, utilities, and easements.
5. Include property lines, lot numbers, and dimensions for each lot.
6. Provide a title block with details including the name of the subdivision, date, and project information.
7. Prepare a signature block for approvals from relevant authorities.
8. Check for compliance with zoning and subdivision regulations specific to your area.
9. Submit the plat for review by local planning and zoning offices.
10. Make any necessary revisions and resubmit until approved.

Who needs Subdivision Plat?

1. Developers planning to subdivide land into individual lots.
2. Homebuyers and real estate investors seeking clear property boundaries.
3. Local government agencies for zoning and urban planning purposes.
4. Surveyors who prepare the plat for legal and record-keeping needs.

People Also Ask about

How do you read a subdivision plat map?

Understanding the Basics Boundaries: Solid lines on a plat map represent the boundaries of lots, tracts, or parcels of land. Dimensions: The dimensions of each lot are usually indicated on the plat map. Streets and Easements: Streets are usually shown with two parallel lines, and their names are often indicated.

What do the numbers mean on a survey map?

The numbers indicate three units of measurement — degrees, minutes, and seconds — while the letters indicate the cardinal direction of the measurement.

What is a plat in a subdivision?

A plat is a map of a land area, usually on the scale of a neighborhood or county township, and a plot is a piece of land used for a single purpose (such as a park or a home). Essentially, a plat map records the collection of plots that make up a neighborhood.

What does plat mean in English?

: a small piece of ground (such as a lot or quadrat) : plot. 2. : a plan, map, or chart of a piece of land with actual or proposed features (such as lots) also : the land represented. plat.

What information is shown on a plat?

A plat map is an official document created by surveyors that shows the exact boundaries of each piece of land within a given area. A plat map shows details like streets, bodies of water, rights-of-way, buildings, and other features, such as parks or public utilities, that may affect who owns or uses the tract of land.

How to find property lines with a plat map?

You can use the plat from the last time the home was surveyed to trace your property lines. Start from the point of beginning and use a compass and plenty of measuring tape. Mark down the measurements as you go. For accuracy, you may want to measure each property line a few different times.

What are the characteristics of a subdivision plat map?

Plat of a subdivision: This kind of plat will show an entire subdivision, its legal borders and individual plots that are within property lines. Amending plat: If you make updates to a property, you also need to make the updates to your plat map.

What is subdivision in American English?

The act of separating something into parts is also called subdivision. In North America, when someone mentions a subdivision, they probably mean a suburban neighborhood.

For pdfFiller’s FAQs

What is Subdivision Plat?

A Subdivision Plat is a detailed map or drawing that illustrates the division of land into several lots, along with associated utilities, streets, and easements.

Who is required to file Subdivision Plat?

The property owner or developer planning to subdivide land is typically required to file a Subdivision Plat with local government authorities.

How to fill out Subdivision Plat?

To fill out a Subdivision Plat, the developer must provide information such as property boundaries, lot dimensions, access roads, and any relevant zoning information, often using professional surveying services.

What is the purpose of Subdivision Plat?

The purpose of a Subdivision Plat is to provide a clear and legal record of the division of land, aiding in development approval, property sales, and future land use planning.

What information must be reported on Subdivision Plat?

Information that must be reported includes the legal description of the property, lot sizes, street layouts, utility layouts, easements, and any zoning or planning regulations applicable.
