How to fill out shop drawing review

First, it is important to understand what a shop drawing review is. A shop drawing review is the process of evaluating and checking the detailed drawings and plans submitted by contractors, subcontractors, or manufacturers. It ensures that the proposed design, materials, and construction methods align with the specifications and requirements of the project.

Now, let's break down the steps on how to fill out a shop drawing review:

1. Obtain the shop drawing package: Start by collecting all the necessary documents, including the shop drawings, specifications, project plans, and any other relevant information. Ensure that you have a complete set of drawings and that they are clearly labeled.
2. Familiarize yourself with the project requirements: Before reviewing the shop drawings, thoroughly read and understand the project requirements, specifications, and design criteria. This will help you assess the drawings and identify any potential discrepancies or non-compliance.
3. Review the shop drawings systematically: Go through the drawings one by one, paying attention to details such as dimensions, materials, finishes, connections, and overall suitability. Compare the drawings against the project requirements to ensure that they meet all the necessary criteria. Look for any errors, omissions, or conflicts with other trades.
4. Check for coordination with other trades: As you review the shop drawings, consider their coordination with other trades involved in the project. Look for clashes, interferences, or conflicts with existing or proposed systems. Communicate with the respective trades or professionals if necessary to resolve any issues.
5. Document your findings: It is crucial to document any discrepancies, concerns, or observations while reviewing the shop drawings. Use a standardized form or template to record your comments or mark the drawings directly if feasible. Clearly state the issue, propose a solution if possible, and indicate the required revisions or corrections.
6. Communicate with stakeholders: Once you have completed your review and prepared your comments, communicate your findings to the relevant parties. This typically includes the contractor, project manager, architects, and any other involved stakeholders. Clearly explain your observations, highlight any critical issues, and provide them with the necessary documentation or marked-up drawings.

Who needs shop drawing review:

1. Architects and engineers: Architects and engineers require shop drawing review to ensure that the proposed design aligns with the project requirements and specifications. They use these reviews to verify structural integrity, safety considerations, and adherence to building codes.
2. Contractors and subcontractors: Contractors and subcontractors rely on shop drawing reviews to validate the construction details and methods proposed in their drawings. This helps them ensure quality control, coordination with other trades, and compliance with project requirements.
3. Construction managers and project owners: Construction managers and project owners benefit from shop drawing reviews as they allow them to monitor progress, mitigate risks, and ensure that the project is being executed as planned. They use these reviews to assess the constructability, functionality, and compliance of the proposed designs.

In conclusion, filling out a shop drawing review involves obtaining the necessary documents, familiarizing yourself with the project requirements, systematically reviewing the shop drawings, checking for coordination with other trades, documenting findings, and communicating with stakeholders. Architects, engineers, contractors, subcontractors, construction managers, and project owners all need shop drawing reviews to ensure the successful execution of a construction project.
