1. Gather relevant data: Collect information about the building's cooling load requirements.
2. Select a suitable chilled water system type: Decide on a system (e.g., centrifugal, screw, or scroll chillers) based on the cooling load and application.
3. Determine system capacities: Calculate the required capacity of chillers based on the peak cooling load.
4. Design the distribution layout: Plan the piping layout for efficient chilled water distribution, considering pump placement and insulation needs.
5. Choose equipment: Select appropriate components like pumps, valves, and cooling towers that match the system specifications.
6. Calculate pressure drops: Analyze the system to determine pressure drops across the various components.
7. Prepare the schematic: Create a detailed schematic diagram showing all connections and equipment locations.
8. Review local codes: Ensure that the design complies with local building and mechanical codes.
9. Finalize documentation: Compile all design calculations, layouts, and specifications into a final design document.
